Crown CDi 1000 275W 2-Channel Solid-State Power Amplifier
Crown CDi Series amplifiers are professional tools designed and built for installed sound applications. The series includes four models which are identical except for output power: CDi 1000, CDi 2000, CDi 4000, and CDi 6000. All are rugged and lightweight, and offer unmatched value in their class.
Extremely versatile; rated for 2-, 4-, 8-ohm loads and 70V and 140V outputs.
Switch-mode universal power supply.
Intuitive front-panel LCD screen for quick, easy configuration.
Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting.
Up to 20 user defined DSP presets are available.
Power
2 ohm dual (per channel): 700W
4 ohm dual (per channel): 500W
8 ohm dual (per channel): 275W
4 ohm bridge-mono: 1,400W
70V dual (per channel): 500W
140V bridge-mono: 1,000W
Crown CDi Series amplifiers are professional tools designed and built for installed sound applications. The series includes four models which are identical except for output power: CDi 1000, CDi 2000, CDi 4000, and CDi 6000. All are rugged and lightweight, and offer unmatched value in their class.
Extremely versatile; rated for 2-, 4-, 8-ohm loads and 70V and 140V outputs.
Switch-mode universal power supply.
Intuitive front-panel LCD screen for quick, easy configuration.
Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting.
Up to 20 user defined DSP presets are available.
Power
2 ohm dual (per channel): 700W
4 ohm dual (per channel): 500W
8 ohm dual (per channel): 275W
4 ohm bridge-mono: 1,400W
70V dual (per channel): 500W
140V bridge-mono: 1,000W
Accurate, uncolored sound with very low distortion for the best in music and voice reproduction
Extremely versatile; rated for 2, 4, 8 ohm loads and 70V/100V and 140V outputs
Advanced protection circuitry guards against: shorted outputs, open circuits, DC, mismatched loads, general overheating, high-frequency overloads and internal faults
Intuitive front-panel LCD screen for quick, easy configuration
Switch-mode universal power supply
Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting
2U rack space
Barrier strip outputs for low-Z or 70V/100V/140V loads, removable Phoenix-style inputs
Three-year, no-fault, fully transferrable warranty completely protects your investment and guarantees its specifications
Extremely versatile; rated for 2, 4, 8 ohm loads and 70V/100V and 140V outputs
Advanced protection circuitry guards against: shorted outputs, open circuits, DC, mismatched loads, general overheating, high-frequency overloads and internal faults
Intuitive front-panel LCD screen for quick, easy configuration
Switch-mode universal power supply
Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting
2U rack space
Barrier strip outputs for low-Z or 70V/100V/140V loads, removable Phoenix-style inputs
Three-year, no-fault, fully transferrable warranty completely protects your investment and guarantees its specifications
Frequency Response 20Hz - 20kHz (@ 1W into 4 Ohms)
Sensitivity 1.4V @ 8 Ohms
Signal to Noise Ratio 100dB
Voltage Gain 30.5dB (@ 1kHz, 8 Ohm Rate Output)
Load Impedance Rated for 2-8 Ohms in Stereo Mode
Rated for 4-16 Ohms in Bridge-Mono Mode
Input Impedance 20 kOhms (Nominal)
Output Power
700W @ 2 Ohm Dual (Per Channel)
500W @ 4 Ohm Dual (Per Channel)
275W @ 8 Ohm Dual (Per Channel)
1400W @ 4 Ohm Bridge-Mono
500W @ 70V Dual (Per Channel)
1000W @ 140V Bridge-Mono
Damping Factor Better than 500 from 20 to 400Hz
Crosstalk >70dB Below Rated Power, 20Hz to 1kHz
Max Input Signal +22dBu Typical
Inputs 2 x 3-Pin Removable Phoenix-Type
Outputs 4-Position Barrier Strip with Connectors for Dual Loudspeakers or Bridge-Mono Loudspeaker
Power 100V, 120V-240V, 50/60 Hz
Dimensions (WxHxD) 19 x 3.5 x 12.25" (483 x 89 x 311mm)
Weight 19 lb (8.6 kg)
Sensitivity 1.4V @ 8 Ohms
Signal to Noise Ratio 100dB
Voltage Gain 30.5dB (@ 1kHz, 8 Ohm Rate Output)
Load Impedance Rated for 2-8 Ohms in Stereo Mode
Rated for 4-16 Ohms in Bridge-Mono Mode
Input Impedance 20 kOhms (Nominal)
Output Power
700W @ 2 Ohm Dual (Per Channel)
500W @ 4 Ohm Dual (Per Channel)
275W @ 8 Ohm Dual (Per Channel)
1400W @ 4 Ohm Bridge-Mono
500W @ 70V Dual (Per Channel)
1000W @ 140V Bridge-Mono
Damping Factor Better than 500 from 20 to 400Hz
Crosstalk >70dB Below Rated Power, 20Hz to 1kHz
Max Input Signal +22dBu Typical
Inputs 2 x 3-Pin Removable Phoenix-Type
Outputs 4-Position Barrier Strip with Connectors for Dual Loudspeakers or Bridge-Mono Loudspeaker
Power 100V, 120V-240V, 50/60 Hz
Dimensions (WxHxD) 19 x 3.5 x 12.25" (483 x 89 x 311mm)
Weight 19 lb (8.6 kg)
